| DIMENSIONS |
| Body Type | | Wide |
| Exterior | L x W x H (mm) | 5325 x 1855 x 1815 |
| Wheelbase | (mm) | 3090 |
| Tread | Front (mm) / Rear (mm) | 1535 / 1550 |
| Overhang | Front (mm) / Rear (mm) | 985 / 1255 |
| Min. Running Ground Clearance* | (mm) | 310 |
| Min. Turning Radius | Body (m) | 6.7 |
| Interior | L x W x H (mm) | 1697 x 1480 x 1170 |
| Seating Capacity (persons) | | 5 |
| Gross Vehicle Weight | Total (kg) | 2910 |
| Curb Weight | Min. Options (kg) | 2060 |
| Fuel Tank Capacity | Total (L) | 80 |
| * (W/O axle, 1 passenger) |
| ENGINE SPECIFICATION |
| Engine Code | | 1GD-FTV (Hi) |
| Variable Nozzle Turbocharger | | o |
| Intercooler | | o |
| Displacement (cm3) | | 2755 |
| No. of Cyls. & Arrangement | | 4 cylinders, IN LINE |
| Fuel System | | COMMON-RAIL DIESEL ENGINE (D-4D) |
| Max. Output (kW @ rpm) | | 150 @ 3,000 - 3,400 |
| Max. Torque (N·m @ rpm) | | 500 @ 1600 - 2800 |
| PERFORMANCE |
| Exhaust Emission Standard | | EURO-II |
| Transmission | Code | AC60F |
| Type | 6-Speed Manua |
| Transfer | System | Part-Time H2, H4, L4 |
| Type | Switch Type |
| Differential Lock | | o |
| Drive Modes (Eco / Pwr s/w) | | o |
| Brake Type | Front | Ventilated Disc |
| Rear | LT Drum |
| Brake Control Valve | | ABS + EBD + BA |
| Tire & Wheel | Type | 265/60R18 Rocco Design Alloy |
| Suspension Type | Front / Rear | Double Wishbone / Leaf Rigid |
| Stabilizer Bar | Front | o |
| Cruise Control | | o |
| Steering Type | Type | Hydraulic Power Steering with Variable Flow Control |
| Adjustments | Tilt & Telescopic |
| EXTERIOR |
| Headlamp | Bulb | Bi-Beam LED PES |
| Leveling | Automatic |
| System | Smart (Auto Operate & Follow-Me) |
| Daytime Running Lamps | | o |
| Front Grille | | Material Black with Black Outer Grille and Chrome
Garnish |
| Front Foglamp | | LED with Exclusive Bezel |
| Side-turn Signal | | On Outer Mirrors |
| Outer Rear View Mirror | | Material Black + Power Retractable |
| Door Handle | | Material Black |
| Doorbelt Moulding | | Silver |
| Over-fender Moulding | | Rocco Design Over Fender |
| Hood Moulding | | Material Black |
| Side Visors | | o |
| Side-Step | | o |
| Sports Bar | | O (with Deck Illumination) |
| Deck Guard Frame | | x |
| Rear Glass | | Sliding |
| Taillamps | | LED |
| High Mount Stop Lamp | | LED |
| Tailgate Handle | | Material Black with Tailgate Garnish |
| Bumper | Front | Painted Rocco Design with Gray Painted Skid Plate |
| Rear | Gray Paint with Step |
| Mud Guard | | Front + Rear |
| Air Spats | | Front + Rear |
| INTERIOR |
| Cabin Scheme | | Black |
| Seat Material | | Leather |
| Door Trim | | Leather / Silver |
| Instrument Panel | | Chrome + Silver / Black |
| Console Box | | O (With Air Register) |
| Power Door Lock | | With Speed Auto Lock |
| Push Start | | o |
| Wireless Key | | Smart Key with Panic Button |
| Door Handle | | Chrome |
| Power Windows | | o |
| Window Wiper | | Time Adjust Intermittent + Mist |
| Illuminated Entry System | | o |
| Coat Hook | | o |
| Shopping Hook | | o |
| Sun Visor | | D + P (Mirror w/ Lid) |
| Heater | | o |
| Climate Control | | Dual Zone Auto A/C |
| Side Defroster | | o |
| Cool & Hot Box | | o |
| Head Rest | Front Seat | Separate, D + P |
| Rear Seat | Separate, 2 |
| Rear Armrest | | O (with Cup Holders x 2) |
| Front Seat | Type | Separate / Premium |
| System | Driver Seat Powered |
| Slide Adjustment | Driver + Passenger |
| Recline Adjustment | Driver + Passenger |
| Height Adjustment | Driver-Side |
| Rear Seat | | 60:40 Split Tip-up |
| Accessory Connector | 12 V DC | O (2 Connectors) |
| 220 V AC | o |
| Steering | Type | Leather |
| Fingertip Controls | Audio, Tel, VR, MID Premium |
| Speedometer | | Premium Optitron with Metal-Tone Dials |
| Multi Info Display | | Large Colour TFT |
| Economy Meter | | o |
| Infotainment System | Screen | 8" Capacitive Display (New) |
| Inputs | Bluetooth, USB Port, MIC, Car Play, Android Auto (New) |
| Navigation | With Android Auto/ Car Play (New) |
| Speakers | 6 Speakers |
| Rear Camera | o |
| SAFETY |
| Vehicle Stability Control | | WITH A-TRC + HAC + TSC + DAC + LSD |
| Emergency Brake Signal | | o |
| Drive Start Control | | o |
| Tire-Turning Angle (Shown in MID) | | o |
| Clearance Sonar | | Front x 2 + Rear x 4 |
| Engine Oil Leveling Warning | | o |
| Light Reminder | | o |
| Key Reminder | | Smart Key Function |
| Shift-Lock System | | o |
| Clutch-Start Safet | | x |
| Anti-Theft System | | Immobilizer With Horn |
| Anti-Lock Braking System | | o |
| Seatbelt | Front Seat | 3-point ELR x 2 + P/T + F/L |
| Rear Seat | 3-point ELR x 3 |
| Child-Restraint System | ISOFIX Child Seat Anchors | o |
| SRS Airbag | Front Airbag | Dual (Driver + Passenger) |
| Knee Airbag | Driver |
| On/Off Switch | o |
| Airbag Indicator | o |
*Indus Motor Company reserves the right to alter any details of specifications and equipment without notice. Vehicles shown and specifications mentioned herein may vary from models and equipment available.
|
